YouthPOWER
1 / 4
| Model | YP-280HV 614V-172KWH |
|---|---|
| Combination Method | 192S1P |
| Rated Capacity | Typical: 280Ah | Minimum: 276Ah |
| Factory Voltage | 614.4 - 633.6V |
| Voltage at End of Discharge | ≤ 537.6V |
| Charging Voltage | 672V |
| Internal Impedance | ≤ 150mΩ |
| Max Charging Current (Icm) | 140A |
| Limited Charging Voltage (Ucl) | 700.8V |
| Max Discharging Current | 140A |
| Discharge Cut-off Voltage (Udo) | 480V |
| Operation Temperature Range | Charge: 0 ~ 55℃ | Discharge: -20 ~ 55℃ |
| Storage Temperature Range | -20℃ ~ 25℃ |
| Single Module Size/Weight | 778.5 * 442 * 230mm / About 125Kg |
| Main Control Box Size/Weight | 620 * 442 * 222mm / About 22Kg |
| System Size/Weight | 550 * 776 * 1960mm / About 1708Kg |
Integrated high-quality EVE 280AH LFP cells with high cycle life >6000 cycles, ensured cells, modules and BMS.
Features comprehensive protections including over-discharge, over-charge, over-current, and temperature management. The system automatically balances cell current and voltage.
Engineered for long cycle life and superior performance to deliver a maximized return on energy investments.
The complete module structure is non-toxic, non-polluting, and fully environmentally friendly.
Plug & play configuration design ensures simple installation with no additional wiring connections required.
Operational temperature range spanning -20℃ to 55℃ with highly stable discharge efficiency and cycle life.
Broad compatibility with leading inverter brands: GOODWE ET, GROWATT SPH, Deye, Megarevo, and Solis.
A commercial solar battery system is an environmentally friendly technology designed to store electrical energy for use. These systems play a crucial role in a business's energy infrastructure, allowing them to store electricity during low demand periods and release it during high demand.
Our high voltage C&I energy storage system 280Ah series can provide industrial and commercial users with a complete solution of outdoor integrated PV & energy storage system. It can be widely used in scenarios such as charging stations, factories, industrial parks, and commercial buildings.
Our LiFePO4 commercial battery storage systems are designed with safety and performance in mind, meeting global standards for quality and reliability. It has key international certifications, including UL 1973, IEC 62619, and CE, ensuring compliance with rigorous safety and environmental standards. Additionally, it is certified for UN38.3, demonstrating its safety for transportation, and comes with a MSDS (Material Safety Data Sheet) for safe handling and storage.
Choose our commercial battery storage for a secure, sustainable, and efficient energy solution that is trusted by industry professionals worldwide.
Our 172kWh-614V 280Ah commercial ESS is securely packed using durable foam and sturdy cartons to ensure protection during transit. Each package is clearly labeled with handling instructions and complies with UN38.3 and MSDS standards for international shipping. With efficient logistics, we offer fast and reliable shipping, ensuring the battery reaches customers quickly and safely. For global delivery, our robust packing and streamlined shipping processes guarantee the product arrives in perfect condition, ready for use.
Our other solar battery series: Residential Battery | Inverter Battery
| Battery Cell | EVE 3.2V 280Ah LiFePO4 cell |
|---|---|
| Single Commercial Battery Pack | 14.336kWh-51.2V 280Ah LiFePO4 rack battery |
| Whole Commercial ESS | 171.92kWh- 614V 280Ah (12 units in series) |
Customize your commercial battery backup system! We offer flexible OEM/ODM services—tailor battery capacity, design, and branding to fit your projects. Fast turnaround, expert support, and scalable solutions for commercial and industrial energy storage.
The system integrates premium-grade EVE 3.2V 280Ah LiFePO4 (LFP) cells, renowned for their safety, stability, and high cycle performance exceeding 6000 cycles.
The built-in intelligent Battery Management System (BMS) offers comprehensive protection against over-discharge, over-charge, over-current, and extreme temperature conditions. It also balances current and voltage across all cells dynamically.
The system features a wide working temperature range. It allows charging between 0℃ and 55℃, and discharging from -20℃ up to 55℃, maintaining excellent cycle life throughout.
Our system boasts wide compatibility with major industry-leading inverter models, including GOODWE ET, GROWATT SPH, Deye, Megarevo, and Solis.
The commercial ESS has successfully obtained critical international safety and shipping certifications, including UL 1973, IEC 62619, CE, UN38.3, and is supplied with an official Material Safety Data Sheet (MSDS).
Yes, we provide flexible OEM/ODM manufacturing options. You can work with us to customize storage capacity, physical styling, configuration, and branding to perfectly align with your commercial and industrial projects.
