| Parameter | Specification (YP-280HV 460V-129KWH) |
|---|---|
| Combination method | 144S1P |
| Rated Capacity | Typical: 280Ah | Minimum: 276Ah |
| Factory Voltage | 460.8V - 475.2V |
| Voltage at end of Discharge | ≤ 388.8V |
| Charging Voltage | 504V |
| Internal Impedance | ≤ 120mΩ |
| Max Charging Current(Icm) | 140A |
| Limited Charging Voltage(Ucl) | 525.6V |
| Max Discharging current | 140A |
| Discharge Cut-off voltage(Udo) | 360V |
| Operation Temperature Range | Charge: 0 ~ 55℃ | Discharge: -20 ~ 55℃ |
| Storage Temperature Range | -20℃ ~ 25℃ |
| Single Module Size/Weight | 778.5 * 442 * 230mm / About 125Kg |
| Main Control Box Size/Weight | 620 * 442 * 222mm / About 22Kg |
| System Size/Weight | 555 * 776 * 1700mm / About 1450Kg |
A commercial solar battery system is an environmentally friendly technology designed to store electrical energy for subsequent use. These systems play a crucial role in a business's energy infrastructure, allowing them to store electricity during low demand periods and release it during peak demand intervals.
Our high-voltage C&I energy storage system 280Ah series provides industrial and commercial users with a complete solution for outdoor integrated PV & energy storage systems. It can be widely utilized in scenarios such as charging stations, factories, industrial parks, and commercial buildings.
Our LiFePO4 commercial battery storage systems are designed with safety and performance in mind, meeting global standards for quality and reliability. It has key international certifications, including UL 1973, IEC 62619, and CE, ensuring compliance with rigorous safety and environmental standards. Additionally, it is certified for UN38.3, demonstrating safety for transportation, and comes with an MSDS (Material Safety Data Sheet) for safe handling and storage.
Choose our commercial battery storage for a secure, sustainable, and efficient energy solution that is trusted by industry professionals worldwide.
Our 129kWh-460V 280Ah commercial ESS is packaged securely using durable foam and sturdy cardboard to ensure maximum protection during transit. Each package is clearly labeled with handling instructions and adheres to UN38.3 and MSDS standards for international shipping. With efficient logistics, we offer fast and dependable shipping, ensuring the battery reaches customers quickly and safely.
| Configuration Level | Details |
|---|---|
| Battery Cell | EVE 3.2V 280Ah LiFePO4 cell |
| Single Commercial Battery Pack | 14.336kWh-51.2V 280Ah LiFePO4 rack battery |
| Whole Commercial ESS | 129.024kWh- 460.8V 280Ah (9 units in series) |
Customize your commercial battery storage for solar! We offer flexible OEM/ODM services, including customizing battery capacity, design, and branding to meet your specific projects. Benefit from fast turnaround, expert support, and highly scalable solutions engineered for commercial and industrial energy storage applications.
The system utilizes high-quality EVE 3.2V 280Ah LiFePO4 cells. A single rack module outputs 14.336kWh at 51.2V, and the complete commercial energy storage system (ESS) is configured with 9 units in series, providing a total of 129.024kWh at 460.8V.
This commercial system is fully compatible with top-tier global inverter brands, including GOODWE ET, GROWATT SPH, Deye, Megarevo, and Solis.
Our commercial battery storage systems comply with international safety regulations and hold major certifications such as UL 1973, IEC 62619, CE, UN38.3, and come with a standard Material Safety Data Sheet (MSDS) for transport safety.
The system supports charging at temperatures between 0℃ and 55℃, and discharging from -20℃ to 55℃. It can be safely stored at temperatures ranging from -20℃ to 25℃.
We offer comprehensive OEM/ODM solutions tailored to your commercial projects. This includes customizing the storage capacity, physical system dimensions, hardware styling, and brand labeling.
Each unit is packaged in a secure safety UN Box wrapped with high-density foam padding. Palletized shipments arrange 12 units per pallet, allowing up to 140 units in a 20ft container and approximately 250 units in a 40ft shipping container.
