YouthPOWER
1 / 5
| Model | YP-280HV 358V-100KWH |
|---|---|
| Combination method | 112S1P |
| Rated Capacity | Typical: 280Ah | Minimum: 276Ah |
| Factory Voltage | 358.4-369.6V |
| Voltage at end of Discharge | ≤302.4V |
| Charging Voltage | 392V |
| Internal Impedance | ≤110mΩ |
| Max Charging Current (Icm) | 140A |
| Limited Charging Voltage (Ucl) | 408.8V |
| Max Discharging current | 140A |
| Discharge Cut-off voltage (Udo) | 280V |
| Operation Temperature Range | Charge: 0~55℃ | Discharge: -20~55℃ |
| Storage Temperature Range | -20℃~25℃ |
| Single module Size/weight | 778.5*442*230mm / About 125Kg |
| Main control box size/weight | 620*442*222mm / About 22Kg |
| System size/weight | 550*776*1985mm / About 850Kg |
Customize your commercial battery energy storage system! We offer flexible OEM/ODM services—tailor battery capacity (50kWh~1MW+), design, and branding to fit your projects. Fast turnaround, expert support, and scalable solutions for commercial and industrial energy storage.
Our other solar battery series: High voltage batteries | All In One ESS.
| Component Type | Specification Details |
|---|---|
| Battery Cell | EVE 3.2V 280Ah LiFePO4 cell |
| Single Battery Module | 14.336kWh-51.2V 280Ah LiFePO4 rack battery |
| Whole Commercial ESS | 100.352kWh- 358.4V 280Ah (7 units in series) |
High-quality, integrated EVE 280Ah LFP cells with a cycle life of >6000 cycles, ensuring high reliability for cells, modules, and BMS.
Features protective functions against over-discharge, over-charge, over-current, and extreme temperature conditions. Automatically manages status, balancing current and voltage for each cell.
Provides long cycle life and superior energy efficiency performance to lower operations expense.
The entire module structure is non-toxic, non-polluting, and manufactured using environmentally responsible materials.
Plug & play modular design. Easy setup requiring no additional wiring connection between modules.
Working temperature range from -20℃ to 55℃, demonstrating excellent discharge performance and long cycle life.
Fully compatible with market-leading high-voltage inverter brands: GOODWE ET, GROWATT SPH, Deye, Megarevo, Solis.
A commercial battery storage system is an environmentally friendly technology designed to store electrical energy for subsequent use. These systems play a crucial role in a business's energy infrastructure, allowing them to store electricity during low demand periods and release it during high demand.
Our high voltage commercial and industrial energy storage system 280Ah series can provide industrial and commercial users with a complete solution of outdoor integrated PV & energy storage system. It can be widely used in scenarios such as charging stations, factories, industrial parks, and commercial buildings.
Related C&I energy storage applications:
Our high-voltage commercial energy storage battery systems are certified with UN38.3 and strictly control the packaging quality during shipment to ensure that each battery system is protected by multiple layers to prevent any damage during transportation. With the use of advanced shock-proof materials and precise packaging, we guarantee the safety of battery storage. Our efficient and professional logistics partners guarantee prompt delivery and strive to provide high-quality products to customers in the shortest amount of time to protect your business.
Our residential and commercial lithium battery storage utilizes advanced lithium iron phosphate technology to deliver exceptional performance and superior safety. Each LiFePO4 battery storage unit has received certifications from various international organizations, including MSDS, UN38.3, UL1973, CB62619, and CE-EMC. These certifications verify that our products meet the highest quality and reliability standards globally. In addition to delivering outstanding performance, our batteries are compatible with a wide range of inverter brands available on the market, providing customers with greater choice and flexibility. We remain dedicated to providing reliable and efficient energy solutions for both residential and commercial applications, catering to the diverse needs and expectations of our customers.
