Buy High voltage rack lifepo4 cabinets Company, Companies

High voltage rack lifepo4 cabinets OEM / ODM How does this sound ? During a power outage, or when the sun goes down, or even when energy prices are highest, wouldn’t you like to use the power you’ve generated all day when the sun was shining? The YouthPower battery allows you to store all the energy your produce from your solar panels – to use whenever you want or need to use it!

Product Description

Energy Storage Battery Model
Model No. YP 3U-24100 YP 2U-4850 / YP 2U-5150 YP 4U-48100 / YP 4U-51100 YP 5U-48150 / YP 5U-51150 YP 5U-48200 / YP 5U-51200
Voltage 25.6V 48V/51.2V
Combination 8S1P 15S/16S 1-4P
Capacity 100AH 50AH 100AH 150AH 200AH
Energy 2.56KWH 2.4KWH 5KWH 7KWH 10KWH
Weight 27KG 23/28KG 46/49KG 64/72KG 83/90KG
Cell 3.2V 50AH & 100AH UL1642
BMS Built-in Battery Management System
Connectors Waterproof connector
Dimension 430*420*133mm 442x480x88mm 483x460x178mm 483x620x178mm 483x680x178mm
Cycles (80% DOD) 6000 cycles
Depth of discharge Up to 100%
Lifetime 10 years
Standard charge 20A 20A 50A 50A 50A
Standard discharge 20A 20A 50A 50A 50A
Maximum continuous charge 100A 50A 100A 100A 120A
Maximum continuous discharge 100A 50A 100A 100A 120A
Operation temperature Charge: 0-45℃, Discharge: -20--55℃
Storage temperature Keep at -20 to 65℃
Protection standard Ip21
Cut off voltage 45V
Max.charging voltage 54V
Memory effect None
Maintenance Maintenance free
Compatibility Compatible with all standard off-grid inverters and charge controllers. Battery to inverter output sizing keep 2:1 ratio.
Warranty Period 5-10 Years
Remarks Rack battery BMS must be wired in parallel only. Wiring in series will void the warranty. Allow max 14 units in parallel to expand more capacity.
Battery Production Details
Battery Production Layout
Battery Storage View
Battery Interior Setup
Shipping & Packaging Solution

The shipping packaging of the High-Voltage Rack Energy Storage Battery Solution demonstrates a high level of professionalism and efficiency. It takes into consideration the weight and size of the batteries, utilizing durable materials and precise linings to ensure safe transportation and handling without damage.

Each battery module is carefully packaged and sealed to protect against external environmental factors, vibration, and impact damage. The professional packaging also includes detailed identification and documentation, clearly stating operating and safety instructions for customer safety.

These measures result in reduced transportation losses, lower maintenance costs, improved customer satisfaction, and enhanced product reliability.

Overall, the attention to product quality and customer experience displayed in the shipping packaging makes it an ideal choice for trust and selection.

Other Solar Battery Series: High voltage batteries, All In One ESS
Solar Battery Alternative 1
Solar Battery Alternative 2
  • 20' container: Total about 140 units
  • 40' container: Total about 250 units
  • 5.1 PC / safety UN Box
  • 12 Piece / Pallet
Storage Packaging Detail 1
Storage Packaging Detail 2
Storage Packaging Detail 3
Storage Packaging Detail 4
Storage Packaging Detail 5
Storage Packaging Detail 6
Storage Packaging Detail 7
Storage Packaging Detail 8
Storage Packaging Detail 9
Storage Packaging Detail 10
Storage Packaging Detail 11
High Voltage Rack LiFePO4 Cabinets OEM / ODM

During a power outage, or when the sun goes down, or even when energy prices are highest, wouldn't you like to use the power you've generated all day when the sun was shining?

The battery allows you to store all the energy you produce from your solar panels – to use whenever you want or need to use it!

You also get to save on your electricity bills by charging the battery during off-peak times, and discharging during peak times.

We place the highest priority on safety and utilize the same technology in automotive batteries.

Customize your battery energy storage system! We offer flexible OEM/ODM services—tailor battery capacity, design, and branding to fit your projects. Fast turnaround, expert support, and scalable solutions for commercial and industrial energy storage.

Battery OEM Customization
Battery Design Layout

The high-voltage rack-mounted energy storage battery solution is specifically designed for commercial solar energy storage systems. It offers a wide range of applications, exceptional power characteristics, and high energy density, ensuring long service life and stable operation.

This solution supports customized design, allowing for flexible configuration and optimization based on specific customer needs to achieve optimal performance and cost-effectiveness.

Main Features:
  • Long cycle life - product life expectancy of 15-20 years
  • Modular system allows storage capacity to be easily expandable as power needs increase.
  • Proprietary architecture and integrated battery management system (BMS) - no additional programming, firmware, or wiring.
  • Operates at unparalleled 98% efficiency for more than 5000 cycles.
  • Can be rack mounted or wall mounted in a dead space area of your home / business.
  • Offer up to 100% depth of discharge.
  • Non-toxic and non-hazardous recyclable materials - recycle at end of life.
Features Infographic 1
Features Infographic 2
Rack Mount Application
Cabinet Integration

LFP is the safest, most environmentally friendly chemistry available. They are modular, lightweight and scalable for installations. The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile. Enjoy easy installation and cost efficiency with the Home Solar Wall Battery. We are always ready to supply first-class products and meet the various needs of our customers.

Installation Overview 1
Installation Overview 2
Installation Overview 3
Quickly Get Your OEM ODM Solution
Frequently Asked Questions
What are the main advantages of using LiFePO4 (LFP) chemistry in these batteries?
LFP (Lithium Iron Phosphate) is the safest and most environmentally friendly battery chemistry available. It offers exceptional stability, high efficiency, a long lifespan of 15-20 years, is non-toxic, and can be fully recycled at the end of its life.
Can these batteries be wired in series to increase voltage?
No. These rack batteries must be wired in parallel only. Wiring them in series will void the warranty. You can connect a maximum of 14 units in parallel to expand capacity.
How does the integrated Battery Management System (BMS) function?
The built-in BMS protects the battery from overcharge, over-discharge, over-current, and temperature extremes. Because it features a proprietary integrated architecture, it requires no additional programming, firmware, or complex wiring during installation.
What is the recommended size ratio between the battery and the inverter?
To ensure safe and optimal performance, the sizing ratio of the battery to the inverter output should be kept at 2:1. The batteries are compatible with all standard off-grid inverters and charge controllers.
What customization options are available under OEM/ODM services?
We offer flexible OEM/ODM solutions tailored to your projects, including customizable battery capacities, custom product dimensions/designs, and custom branding or labeling.
Where can these batteries be mounted?
These modular batteries are highly flexible; they can be mounted in standard racks or fixed directly to walls, allowing you to utilize dead space in both residential and commercial premises.
