| Model No. | YP-24100-2.56KWH | YP-24200-5.12KWH | YP-24300-7.68KWH |
|---|---|---|---|
| Voltage | 25.6V | 25.6V | 25.6V |
| Combination | 8S2P | 8S4P | 8S6P |
| Capacity | 100AH | 200AH | 300AH |
| Energy | 2.56kWh | 5.12kWh | 7.68kWh |
| Weight | 30Kg | 62Kg | 90Kg |
| Chemistry | Lithium Ferro Phosphate (Lifepo4) Safest Lithium Ion, No fire risk | ||
| BMS | Built-in Battery Management System | ||
| Connectors | Waterproof connector | ||
| Dimension | 680*485*180mm | ||
| Cycles (80% DOD) | 6000 cycles | ||
| Depth of discharge | Upto 100% | ||
| Lifetime | 10 Years | ||
| Standard charge | Constant current: 20A | ||
| Standard discharge | Constant current: 20A | ||
| Maximum continuous charge | 100A/200A | ||
| Maximum continuous discharge | 100A/200A | ||
| Operation temperature | Charge: 0-45℃, Discharge: -20-55℃ | ||
| Storage Temperature | Keep at -20 to 65℃ | ||
| Protection standard | Ip21 | ||
| Operation voltage | 20-29.2 VDC | ||
| Max.charging voltage | 29.2 VDC | ||
| Memory effect | None | ||
| Maintenance | Maintenance free | ||
| Compatibility | Compatible with all standard offgrid inverters and charge controllers. Battery to inverter output sizing keep 2:1 ratio. | ||
| Warranty Period | Warranty 5-10 years | ||
| Remarks | The 24V wall battery BMS must be wired in parallel only. Wiring in series will void the warranty. Allow max. 4 units in parallel to expand more capacity. | ||
24v lithium ion battery is a great choice for any solar system that needs to store power. Our logistics system adheres to strict shipping packaging standards to guarantee the impeccable condition of our 24V li ion batteries during transit. Each battery is carefully packaged with multiple layers of protection, effectively protecting against any potential physical damage. Our efficient system ensures prompt delivery and timely receipt of your order.
In remote locations, such as off-grid cabins or campsites, a 24v solar battery can provide reliable backup power for lighting, refrigeration, and other essential equipment. In addition, a 24v solar battery can be used as a primary power source for stand-alone solar-powered systems, such as outdoor lighting, fountains, and more.
Another important application for a 24v solar battery is in emergency preparedness and disaster response. In the event of a power outage or natural disaster, a 24v solar battery can provide critical backup power for emergency lighting, communication devices, and other essential equipment.
Our 24v 100-300AH deep-cycle Lithium Ferro Phosphate (LFP) batteries are optimized with proprietary cell architecture, power electronics, BMS and assembly methods. They are a drop-in replacement for lead acid batteries, and much safer, it is regarded as the best solar battery bank with affordable cost.
Our 24V battery solutions leverage advanced lithium iron phosphate (LiFePO4) technology to deliver exceptional performance and superior safety. Each 24V lithium battery 100Ah-300Ah are certified with MSDS, UN38.3, UL, CB, and CE. These certifications ensure all 24V power supply meet the highest global standards for quality and reliability.
Designed for versatility, our 24V lithium batteries are compatible with a wide range of inverter brands, offering customers enhanced flexibility and choice. Whether for residential or commercial use, we remain committed to providing reliable, efficient, and scalable energy solutions tailored to meet diverse energy demands.
