YouthPOWER
1 / 5
| Model No. | MW48100-4.8KWH | MW51100-5.12KWH |
|---|---|---|
| Voltage | 48V | 51.2V |
| Combination | 15S2P | 16S2P |
| Capacity | 100AH | |
| Energy | 4.8KWH | 5.12KWH |
| Weight | 45KG | 50KG |
| Chemistry | Lithium Ferro Phosphate ( LiFePO4) Safest Lithium Ion, No fire risk | |
| BMS | Built - in Battery Management System | |
| Connectors | Standard Input/Output Terminal | |
| Dimension | 580*390*180mm | |
| Cycles (80% DOD) | 6000 cycles | |
| Depth of discharge | Up to 100% | |
| Life time | 10 years | |
| Standard charge | 50A | |
| Standard discharge | 50A | |
| Maximum continuous charge | 95A | |
| Maximum continuous discharge | 95A | |
| Operation temperature | Charge : 0-45℃, Discharge: -20~55℃ | |
| Storage Temperature | Keep at -20 to 65℃ | |
| Protection standard | IP21 | |
| Cut off voltage | 40.5V | 43.2V |
| Max.charging voltage | 54.75V | 58.4V |
| Memory effect | None | |
| Maintenance | Maintenance free | |
| Compatibility | Compatible with all standard offgrid inverters and charge controllers. Battery to inverter output sizing keep 2:1 ratio. | |
| Warranty Period | 5-10 Years | |
| Remarks | Battery BMS must be wired in parallel only. Wiring in series will void the warranty. | |
As a professional 5kWh LiFePO4 battery supplier, our 5kWh powerwall factory conducts strict testing and inspection on all lithium batteries before shipment to ensure that each battery system meets quality standards and has no defects or defects. This high-standard testing process not only ensures the high quality of lithium batteries, but also provides customers with a better shopping experience.
Furthermore, we strictly follow shipping packaging standards to guarantee the impeccable condition of our 48V 51.2V 100Ah 5kWH battery during transit. Each battery is carefully packaged with multiple layers of protection to effectively protect against any potential physical damage. Our efficient logistics system ensures prompt delivery and timely receipt of your order.
Looking for a lightweight, non-toxic, and maintenance-free energy storage solution as your solar home system?
In our line of Lithium Ferro Phosphate (LFP) batteries, we have the perfect solution for you. With a drop-in replacement for lead acid batteries and much lower weight, these are simply the best solar battery bank with affordable cost.
LFP is the safest, most environmentally friendly chemistry available. They are modular, lightweight and scalable for installations. The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile. Enjoy easy installation and cost with Home SOLAR WALL BATTERY. We are always ready to supply the first-class products and meet the various needs of the customers.
Enjoy easy installation and cost with Home SOLAR WALL BATTERY, We are always ready to supply the first-class products and meet the various needs of the customers.
Our 48V/51.2V 5kWh-10kWh powerwall batteries utilize advanced lithium iron phosphate battery technology to deliver exceptional performance and superior safety. These home energy storage systems have received certifications from international organizations such as MSDS, UN38.3, UL1973, CB62619, and CE-EMC. These certifications confirm that our 48V battery products meet the highest quality and reliability standards globally.
In addition to delivering outstanding performance, our batteries are compatible with a wide range of inverter brands available on the market, such as Deye, Growatt, SMA, GoodWe, Solis, Sol-Ark, and so on, providing customers with greater choice and flexibility.
The power home solar battery 48V 100ah solar power system is a complete solar energy system for your home, with a solar panel, an inverter and a battery. The battery can store energy generated by the solar panel in order to provide electricity when needed.
With this system you can run lights, fans and other devices in your home even when there is no electricity supply.
Our 48V/51.2V 5kWh-10kWh batteries hold international safety and quality certifications including MSDS, UN38.3, UL1973, CB62619, and CE-EMC, meeting the highest standards globally.
These batteries are highly compatible with most standard off-grid inverters and charge controllers on the market, such as Deye, Growatt, SMA, GoodWe, Solis, and Sol-Ark.
The battery BMS must be wired in parallel only. Wiring the batteries in series is not permitted and will void the product warranty.
These batteries use Lithium Ferro Phosphate (LiFePO4) chemistry. It is widely recognized as the safest, most stable, and environmentally friendly lithium-ion chemistry available, presenting zero fire risk.
These batteries have a product life expectancy of 15-20 years (10 years warranty time), offering over 5000 to 6000 cycles at up to 100% depth of discharge with 98% efficiency.
Yes, this is a modular system which allows the storage capacity to be easily expanded as your power demands increase over time.
