| Battery Specifications |
| Model No |
YP48100-4.8KWH V2 YP51100-5.12KWH V2 |
YP48150-7.2KWH V2 YP51150-7.68KWH V2 |
YP48200-9.6KWH V2 YP51200-10.24KWH V2 |
| Nominal Parameters |
| Voltage |
48 V/51.2V |
48 V/51.2V |
48 V/51.2 V |
| Capacity |
100 Ah |
150 Ah |
200Ah |
| Energy |
4.8 /5.12 KwH |
7.2/7.68 KwH |
9.6 /10.24 KwH |
| Dimensions (L x W x H) |
740*530*200mm |
740*530*200mm |
740*530*200mm |
| Weight |
66/70kg |
83/90 kg |
101/110 kg |
| Basic Parameters |
| Life time(25℃) |
10 Years |
| Life cycles(80% DOD, 25℃) |
6000 Cycles |
| Storage time & temp |
5 months @ 25℃; 3 months @ 35℃; 1 month @ 45℃ |
| Lithium Standard |
UL1642(Cell), IEC62619, UN38.3, MSDS, CE, EMC |
| Enclosure rating |
IP21 |
| Electrical Parameters |
| Operation voltage |
48 Vdc |
| Max. charging voltage |
54 Vdc |
| Cut-off Discharge |
42 Vdc |
| Max. current |
100A(4800W) |
120A(5760W) |
120A(5760W) |
| Compatibility |
Compatible with all standard offgrid inverters and charge controllers. Battery to inverter output sizing keep 2:1 ratio. |
| Warranty Period |
5-10 Years |
| Remarks |
Wall battery BMS must be wired in parallel only. Wiring in series will void the warranty. |
| Finger Touch Version |
Available only for 51.2V 200AH, 200A BMS |
As a professional 48V lithium ion solar battery supplier, the lithium battery factory must conduct strict testing and inspection on all lithium batteries before shipment, to ensure that each battery system meets quality standards and has no defects or defects. This high-standard testing process not only guarantees the high quality of lithium batteries, but also provides customers with a better shopping experience.
In addition, we adhere to strict shipping packaging standards to ensure the impeccable condition of our 48V/51.2V 5kWH – 10kWh home battery backup system during transit. Each battery is carefully packaged with multiple layers of protection, effectively protecting against any potential physical damage. Our efficient logistics system ensures prompt delivery and timely receipt of your order.
Other solar battery series:
High voltage batteries | All In One ESS.
The key features of this battery model are:
- 01. Long cycle life - product life expectancy of 15-20 years.
- 02. Modular system allows storage capacity to be easily expandable as power needs increase.
- 03. Proprietary architecture and integrated battery management system (BMS) - no additional programming, firmware, or wiring.
- 04. Exceptional efficiency - operates at unparalleled 98% efficiency for more than 5000 cycles.
- 05. Flexible mounting - can be rack mounted or wall mounted in a dead space area of your home / business.
- 06. Deep discharge - offers up to 100% depth of discharge.
- 07. Environmentally friendly - non-toxic and non-hazardous recyclable materials (recycle at end of life).
Looking for a lightweight, non-toxic, and maintenance-free energy storage solution as your home solar battery?
Deep-cycle Lithium Ferro Phosphate (LFP) batteries are optimized with proprietary cell architecture, power electronics, BMS and assembly methods. They are a drop-in replacement for lead acid batteries, and much safer. It is regarded as the best solar battery bank with affordable cost.
LFP is the safest, most environmentally friendly chemistry available. They are modular, lightweight, and scalable for installations. The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile.
Enjoy easy installation and cost-effectiveness with the Home SOLAR WALL BATTERY. We are always ready to supply the first-class products and meet the various needs of the customers.
Packaging & Shipping Details
Container Capacity:
- 20' container : Total about 100 units
- 40' container : Total about 228 units
Package Content:
- 1 PC / safety UN Box
- 6 Pieces / Pallet
The 48V/51.2V 5kWh-10kWh solar powerwall batteries utilize advanced lithium iron phosphate battery technology to deliver exceptional performance and superior safety. These LiFePO4 battery storage boxes have received certifications from international organizations such as MSDS, UN38.3, UL1973, CB62619, and CE-EMC. These certifications confirm that our 48V battery products meet the highest quality and reliability standards globally. In addition to delivering outstanding performance, our batteries are compatible with a wide range of inverter brands available on the market, such as Deye, Growatt, SMA, GoodWe, Solis, Sol-Ark, and so on, providing customers with greater choice and flexibility.
Enjoy easy installation and cost-effectiveness with the Home SOLAR WALL BATTERY. We are always ready to provide top-notch products and meet the diverse needs of the customers.
The 48V LiFePO4 battery is a versatile and reliable storage device that provides efficient, flexible, and safe power supply for households and small businesses. It not only enhances power quality but also promotes energy conservation and environmental protection. Furthermore, it serves as a convenient and dependable source of power while bringing significant economic benefits.
Frequently Asked Questions (FAQ)
1. Can these home solar wall batteries be wired in series?
No, the wall battery BMS must be wired in parallel only. Wiring in series will void the warranty.
2. Which inverter brands are compatible with this system?
The battery is highly compatible with a wide range of standard inverter brands on the market, including Deye, Growatt, SMA, GoodWe, Solis, and Sol-Ark.
3. What international certifications do these batteries carry?
Our battery systems have received strict certifications confirming global quality and safety standards, including MSDS, UN38.3, UL1973, CB62619, and CE-EMC.
4. What is the expected cycle life and efficiency?
These batteries operate at up to 98% efficiency for more than 5000 cycles, offering a product life expectancy of 15-20 years and up to 100% depth of discharge.
5. How are the batteries packaged for transport?
Each battery is carefully packed in an individual safety UN Box, with 6 pieces arranged per pallet. We adhere to strict shipping packaging standards to prevent physical damage.
6. Is a finger-touch interface version available?
Yes, the finger-touch version is available specifically for the 51.2V 200AH model which features a 200A BMS.
