| Model | YP ESS0820US | YP ESS0830US |
| On Grid AC Output | ||
| Rate AC Output Power | 8KVA | |
| AC Output Voltage | 120/240vac ( split phrase ), 208Vac ( 2/3 phase ), 230Vac ( single phase ) | |
| Ac Output Frenquency | 50/60HZ | |
| Grid Type | Split Phase, 2/3 Phase, Single Phase | |
| Max Output Current | 38.3A | |
| AC reverse charging | Yes | |
| Max Effciency | Over 98% | |
| CEC Efficiency | Over 97% | |
| PV Input | ||
| PV Input Power | 12kw | |
| MPPT Number | 4 | |
| PV Voltage Range | 350V / 85V - 500V | |
| MPPT Voltage Range | 120-500V | |
| Single MPPT Input Current | 12A | |
| Battery | ||
| Normal Voltage | 51.2V | |
| Full Charge Voltage | 56V | |
| Full Discharge Voltage | 45V | |
| Typical Capacity | 400AH | 600AH |
| Maximum Continuous Discharge Current | 190A | |
| Protection | BMS & Breaker | |
| Protection Details | ||
| Ground Protection | YES | |
| AFCI Protection | YES | |
| Islanding Protection | YES | |
| DC Disconnect Detection | YES | |
| Battery Reverse Protection | YES | |
| Insulation Testing | YES | |
| GFCI | YES | |
| DC Anti-Thunder | YES | |
| AC Anti-Thuner | YES | |
| Input Overvoltage & Under Voltage Protection | YES | |
| Output Overvoltage & Under Voltage Protection | YES | |
| AC & DC Over-Current Protection | YES | |
| AC Short-Circuit Current Protection | YES | |
| Overheating Protection | YES | |
| System Parameters | ||
| Dimension : | 570*600*1700mm ( D*W*H ) | |
| Net Weight ( KG ) | 340 | 428 |
| IP Standard | IP54 | |
24v solar batteries are a great choice for any solar system that needs to store power. The LiFePO4 battery we carry is an excellent choice for solar systems up to 10kw as it has extremely low self-discharge and less voltage fluctuation than other batteries.
Our other solar battery series：High voltage batteries All In One ESS.
Deep-cycle Lithium Ferro Phosphate (LFP) batteries are optimized with proprietary cell architecture, power electronics, BMS and assembly methods.
They are a drop-in replacement for lead acid batteries, and much safer, it is regarded as the best solar battery bank with affordable cost. LFP is the safest, most environmentally chemistry available. They are modular, lightweight and scalable for installations.
The batteries provide power security and seamless integration of renewable and traditional sources of energy in conjunction with or independent of the grid: net zero, peak shaving, emergency back-up, portable and mobile. Enjoy easy installation and cost with Home SOLAR WALL BATTERY. We are always ready to supply the first-class products and meet the various needs of the customers.
Lithium Ferro Phosphate (LFP) is widely considered the safest and most environmentally friendly chemistry available for energy storage. It offers high chemical stability, a long cycle life, excellent efficiency parameters, and a lightweight, modular format ideal for home installations.
These solar storage systems run at up to 98% efficiency for over 5000 cycles. Under normal operating conditions, they offer a long service life expectancy of 15 to 20 years.
Yes, absolutely. The system features a modular design that allows capacity to be easily expanded as your power consumption or system configuration demands increase.
The system features comprehensive protections controlled via BMS and physical breakers. These include Ground protection, AFCI protection, Islanding protection, DC disconnect detection, Battery reverse protection, Insulation testing, GFCI, AC & DC surge/anti-thunder protections, and complete over/under-voltage/current protections.
The standard system dimensions are 570*600*1700mm (D*W*H) with IP54 ingress protection rating, making it suitable for versatile indoor or outdoor protected environments. The modular layout allows for easy plug-and-play installation.
For international shipping, products are securely packed in UN boxes (5.1 PC / safety UN Box) with 12 pieces per pallet. A 20-foot container holds approximately 140 units, while a 40-foot container holds approximately 250 units.
